The JCT3628 pipe laser cutting machine with 3D cutting capability expands the 2D laser cutting process to three dimensions. This allows for an endless amount of creativity and design, making it possible to cut more intricate shapes with relative ease. Using 3D cutting function,save 20%-30% cutting time, increase efficiency.
| Model | JCT3628 |
| Power | 1000W-6000W |
| Min.Dia(mm) | 20 |
| Max.Dia(mm) | 280 |
| Tube length(mm) | 3000 / 6000 / 9000 / 12000 |
| Number of Chucks | 3 |
| Maximum tailing length(mm) | 0-100 |
| Maximum revolutions of chuck(RPM) | 80-120 |
| X/Y-axis Positioning Accuracy | ±0.05mm |
| X/Y-axis Repositioning Accuracy | ±0.03mm |
| Positioning speed | 90m/min |
| Max. Acceleration | 1G |
If you’re interested in our products, please feel free to contact us. We’re here to help!
