I. Product Description
This automated exchange table fiber laser cutting production line integrates laser cutting host, dual exchange worktable, vertical sheet storage warehouse and automatic loading & unloading manipulator into one intelligent processing unit, specially customized for medium and large sheet metal processing enterprises pursuing high automation and high output.
Traditional single-table laser cutting machines require frequent manual plate feeding, leading to frequent machine halt and low overall production efficiency. Independent material racks also occupy a large area of factory space, and manual sheet handling easily causes surface scratches and safety accidents. This all-in-one automated laser equipment solves all these production bottlenecks in one set.
The matched sheet storage library realizes classified storage of raw metal plates, and the automatic manipulator completes all material access procedures linked with laser cutting programs. Cooperated with alternating operation of exchange tables, the equipment forms a closed-loop production flow from raw material storage, automatic feeding, continuous cutting to finished parts automatic collection. It is an ideal intelligent upgrading equipment for sheet metal factories to realize unmanned workshop and standardized mass production.
II. Advantages:
Dual Fast Exchange Worktable Design
Two independent worktables switch within 15–25 seconds. One table runs cutting task while the other finishes loading/unloading synchronously, eliminating machine waiting downtime and raising equipment utilization by over 40%.
Integrated Vertical Multi-layer Sheet Storage Library
Vertical tower storage replaces scattered ground material racks, saving over 40% workshop floor space. It stores raw sheets of different materials and thicknesses separately with real-time inventory management.
Full-automatic Vacuum Gantry Loading & Unloading Manipulator
High-strength vacuum suction cup adapts to 0.8–25mm metal sheets. Automatic sheet separation, feeding and unfeeding without manual plate lifting, avoiding scratch and safety risks.
Uninterrupted Batch Production Capacity
Storage tower stores sufficient raw plates to support long-hour continuous cutting. greatly reducing labor input and human operation errors.
High-rigidity Integrated Machine Bed & Stable Cutting Precision
Stress-relief welded bed plus heavy-duty transmission components, repeated positioning accuracy ±0.03mm. Consistent cutting size for mass sheet metal batch production.
Integrated Intelligent Central CNC Control System
One unified control panel manages laser cutting, table exchange, storage library and loading manipulator. Supports automatic nesting, material storage calling and production data statistics.
III. Technical parameters
Model | JLMT3015/JLMT6015/JLMT4020/JLMT6020/JLMT6025/JLMT8025 |
Laser power | 6kW/8kW/10kW/12kW/15kW/20kW/30kW/40kW/ |
CNC Controller | Bochu FSCUT EtherCAT Bus System |
Laser cutting head | Intelligent auto focus laser cutting head |
Effective cutting size | 3000-1500mm/6000-1500mm/4000-2000mm/6000-2000mm/6000-2500mm/8000-2500mm |
Cutting material | MS,SS,Galvanized sheet, Aluminum, Brass,Red copper |
| Laser chiller | Tongfei/Hanli |
Servo motor and Driver | Inovance/Yaskawa/Bochu/Rexroth |
Linear Guide | Rexroth |
Cutting software | Cypcut/HypCut |
Nesting software(Optional) | CypNest |
Electronic pieces | Schneider |
| Voltage Stabilizer | Xinbaoming/Feixiangda |
IV. Application
General Sheet Metal Fabrication: Cabinet, chassis, electrical box, metal bracket batch cutting
Advertising & Decoration Industry: Stainless steel characters, metal decorative parts, signage plates
Machinery Equipment Manufacturing: Mechanical housing, equipment base, structural metal accessories
New Energy Supporting Parts: Energy storage cabinet plates, new equipment metal shells, photovoltaic support plates
Kitchen & Household Hardware: Stainless steel kitchen panels, household appliance metal components
V. Cutting samples for reference
VI. FAQ
Q1: What maximum sheet weight can the automatic storage tower and loading manipulator support?
A1: The storage tower single layer load reaches 3 tons, and the vacuum manipulator supports sheets up to 3000kg per stack. Customized heavy-load storage and handling modules are available for extra thick steel plate production lines.
Q2: Can this automated laser line store multiple different metal materials at the same time?
A2: Yes, the multi-layer vertical storage tower can divide independent storage areas for carbon steel, stainless steel, aluminum and galvanized sheets. The CNC system calls corresponding materials automatically according to cutting drawings.
Q3: Does the whole automated laser production line need special factory foundation construction?
A3: Standard reinforced concrete ground meets installation requirements without deep foundation excavation. The whole line adopts modular split structure, convenient for transportation and on-site assembly within short time.
Q4: What routine maintenance items are needed for the storage and auto loading system?
A4: Daily maintenance mainly includes cleaning vacuum suction cup dust, checking manipulator guide rail lubrication, inspecting storage tower sensor sensitivity and clearing residual steel slag on exchange tables, with low spare parts replacement cost and simple operation.
